Parkway DLX

Year 2023
MSRP $0.00 *
Sizes 20"
Colors Black, Avocado
Weight

The Haro Parkway DLX perpetuates pure freestyle vibes! With front and rear brakes and a detangler for endless trick possibilities, all built onto a 20.3" top tube frame that is performance minded and ready for action. 25/9 micro-gearing, an adjustable railed seat that you can raise as high as you want, along with four pegs for standing, grinding, or hauling the homies.

FEATURES

  • Hi-ten frame with 20.3" top tube
  • 1 1/8" hi-ten threadless fork
  • 7.5" hi-ten bars with Haro alloy top load stem
  • 25/9 gearing with sealed bearing 9T driver
  • Haro padded fully adjustable seat
  • Haro MS5 20 x 2.3" front & rear
  • Alloy 990 brake
  • Four pegs, front 990 brakes and Gyro
SPECIFICATIONS
Frame Components
Frame Full Hi-Ten frame with a 20.3" top tube
Fork Full Hi-Ten 1 1/8" threadless w/ 990 mounts
Headset Threadless loose ball, 1 1/8"
Drivetrain
Cranks Steel 1-pc, 175mm
Sprocket 25T steel
Bottom Bracket Loose ball American BB
Gearing 25/9
Chain Haro Baseline standard link
Pedals Poly Platform, 1/2"
Wheels
Tires Haro MS5 20 x 2.3"
Wheels/Rims 20" alloy 36h, single wall
Front Hub Steel shell 36h, loose ball
Rear Hub Alloy shell cassette, 36h, loose ball with sealed bearing driver
Axle 3/8" front / 14mm rear
Braking System
Brakes Alloy 990 U-Brake front & rear
Brake Levers Alloy two-finger front & rear
Other Components
Grips Haro Stripe grips
Handle Bar Full Hi-Ten, 7.5" rise
Stem Forged Alloy Top-Load, 50mm reach
Seat Haro padded adjustable
Seat Post Steel, 25.4mm
Seat Clamp Alloy, 28.6mm
Pegs Steel, two pair (4 total)
GEOMETRY
Size Head Angle Seat Angle Top Tube Seat Tube Chainstay BB Height Stand Over
20.3 74.5° 70° 516mm (20.3") 260mm (10.2") 349mm (13.7") 293mm (11.5") 546mm (21.5")

RESOURCES

Owner's manual: Bike Manual PDF
