A top rated performer at EBA's bike shoot out, the Shift Plus i/O 7 is quickly becoming one of the most popular and legit eMTB's on the scene. Built upon a 140mm 4 bar link frame paired to a Rockshox Revelation RC 150mm travel fork, the R7 i/O is built with Shimano's e8000 mtb specific mid motor drive system that delivers 250 watts of power, 70 Nm of torque, and 504 watt battery with a 4 hour recharge from flat. Simple light and convenient, Shimano XT 11 speed 1X keeps shifting clean and smooth while the TranzX internal dropper post with remote conveniently puts you in the right position at the right time. Kenda Havoc 27.5" x 2.6" Plus size tires are mounted to WTB i35 double wall rims. What goes down must go up, and with the power of i/O and e8000 you'll want to do it a lot, but when it comes time to stop a Shimano SLX M7000 hydraulic brake set stands ready and able when you are.
FEATURES
- Shift Plus I/O X6 Aluminum frame for Shimano STePS E8000 motor, 140mm travel, tapered head tube 1-1/8"-1.5"
- Rockshox Monarch RL 200mm rear shock, DebonAir, LL Tune, 430 lbs. lockout force
- Rockshox Revelation RC 27.5" Boost fork, 35mm stanchions, 150mm travel, 15mm Stealth Maxle, Solo Air, w/ hydraulic lockout
- Shimano STePS E8000 drive unit / 250 Watts / 70Nm Torque, 500 w/h STePS E8000 battery
- Shimano XT M8000, 11-spd, Shadow Plus rear derailleur, SLX 11-spd, 11-42T cassette
- Shimano E8000 crankarms, forged, 38T chainring
- Shimano SLX M7000 brakeset, 180mm rotors, pads w/ fins
- TranzX Internal dropper post 100mm x 31.6mm
- New Kenda Havoc 27.5" x 2.6" Folding tires
| Frame Components | |
|---|---|
| Frame | Shift Plus I/O X6 Aluminum frame for Shimano STePS E8000, 4-Bar linkage, vertical shock, 140mm travel, Enduro Bearings |
| Fork | RockShox Revelation 27.5" Boost, 35mm stanchions, 15mm Stealth Maxle, Solo Air, 150mm travel, w/ Hydraulic Lockout |
| Headset | FPD Dozer 1-1/8"-1.5", w/ Bottom AC Bearing |
| Frame Shock | RockShox Monarch RL 200x57, DB, LL Tune, 430 lbs. Lockout Force |
| Drivetrain | |
| Cranks | Shimano E8000, forged, 38T Chainring |
| Bottom Bracket | N/A |
| Chain | KMC X11eT Blacktech Anti-Rust (Turbo High Durability), 11-spd |
| Front Derailleur | N/A |
| Rear Deralleur | Shimano XT M8000 11-spd, Shadow Plus |
| Derailleur Shifter | Shimano SLX M7000 11-spd |
| Drive Unit | Shimano STePS E8000, 70Nm Torque |
| Battery | Shimano STePS E8010, 500Wh |
| Pedals | N/A |
| Wheels | |
| Tires | Kenda HAVOC 27.5x2.6", 120tpi, Aramid beads, Pro EMC, Tubeless Compatible |
| Wheels/Rims | WTB i35, Tubeless Ready, 27.5"x40mm, Double Wall |
| Hubs | Pivit Alloy disc Boost, 32h cassette, Sealed Bearings, w/ Front & Rear Thru-Axle |
| Freewheel/Cassette | Shimano SLX M7000, 11-spd, 11-42T |
| Braking System | |
| Brakes | Shimano SLX M7000 Hydraulic Disc w/ Pad Fins, 180mm Rotors |
| Brake Levers | Shimano SLX M7000 Hydraulic |
| Other Components | |
| Grips | Ritchey MTN Trail WCS Locking, 135mm |
| Handle Bar | Race Face Ride Alloy 35mm bar, 20mm rise |
| Stem | Race Face Ride 35mm Forged short alloy |
| Seat | WTB Rocket Comp |
| Seat Post | TranzX Internal Dropper Post, Handlebar Remote, 31.6 x 370mm, 80 or 100mm |
| Extras | Shimano Chain Guide, Tubeless Valves, Dropper post routings, Battery charger, Battery Lock |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS / 14.5 | 67° | 76 / 73° | 570mm (22.4") | 368mm (14.5") | 457mm (18") | 20mm (0.8") | 1164mm (45.8") | 760mm (29.9") | 598mm (23.5") | 413mm (16.3") | 542mm (21.3") | 46mm (1.8") | 60mm | 760mm | 170mm |
| S / 16 | 67° | 76 / 73° | 585mm (23") | 406mm (16") | 457mm (18") | 20mm (0.8") | 1182mm (46.5") | 767mm (30.2") | 607mm (23.9") | 427mm (16.8") | 542mm (21.3") | 46mm (1.8") | 60mm | 760mm | 170mm |
| M / 18 | 67° | 75.7 / 73° | 615mm (24.2") | 457mm (18") | 457mm (18") | 20mm (0.8") | 1213mm (47.8") | 767mm (30.2") | 613mm (24.1") | 456mm (18") | 542mm (21.3") | 46mm (1.8") | 60mm | 760 / 780mm | 175mm |
| L / 20.5 | 67° | 75.7 / 73° | 630mm (24.8") | 520mm (20.5") | 457mm (18") | 20mm (0.8") | 1229mm (48.4") | 786mm (30.9") | 626mm (24.6") | 463mm (18.2") | 542mm (21.3") | 46mm (1.8") | 60 or 70mm | 760 / 780mm | 175mm |
| XL / 22 | 67° | 75.5 / 73° | 640mm (25.2") | 559mm (22") | 457mm (18") | 20mm (0.8") | 1245mm (49") | 810mm (31.9") | 635mm (25") | 476mm (18.7") | 542mm (21.3") | 46mm (1.8") | 60 or 70mm | 760 / 780mm | 175mm |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
