Westlake
| Year | 2021 |
|---|---|
| MSRP | $729.99 * |
| Sizes | S/15.5", M/17.5", L/19", XL/21", XL+/23" |
| Colors | Brushed Polish |
| Weight | 30.5 lbs |
As the world gets unnecessarily more complex: meetings to meet about... ahem... meetings--with this confusing backdrop, one bike--this bike--The Westlake--creates irrefutable simplicity. Lovely, glorious, wondrous simplicity through a wholehearted approach to being a bicycle. Not a gravel bike, not a road bike, not an enduro bike, not a KOM bike, PR bike, aero bike, training bike, or even aero training bike (it does exist, mind you). In a world of needless confusion, The Westlake provides straightforward bicycleness, one direct Shimano 1x9 shift at a time, as it should.
FEATURES
- Simple and efficient 1 x 9 wide-range drivetrain keeps shifting crisp while retaining easy gearing for hills and hard gearing for fast flats
- Dual alloy chainguards prevent the chain from falling off, even over rough terrain
- Quality Tektro hydraulic brakes provide consistent, strong stopping power even in wet conditions
- Lockout suspension fork allows for efficient pavement riding
- Mid-width tires allows for efficient on-road or smooth off-road versatility
- Alloy wheels, frame, and components stay rust free
| Frame Components | |
|---|---|
| Frame | Haro Solum | Heat-treated 6061 aluminum | Tig-welded construction | Rider-tuned geometry | 68mm threaded BSA bottom bracket shell | Post mount disc brake mount | 135mm quick-release dropouts with replaceable derailleur hanger |
| Fork | SR Suntour | SF20 NEX HLO-DS | 63mm travel | Lightweight alloy crown and monocoque lowers | Weather-sealed stanchion protection | Plush coil spring with adjustable preload | Hydraulic Lockout | Post-mount disc brake | 100mm quick-release spacing |
| Headset | Pivit Precision Plus | 1-1/8" threadless | Internal | For 50mm OD headtube |
| Drivetrain | |
| Cranks | 3-piece cold forged alloy | 42T single chainring | 104mm BCD | Dual alloy chainguards | 15.5" & 17.5": 170mm; 19"-23": 175mm |
| Bottom Bracket | Threaded BSA 68mm BB shell | Square taper 118mm spindle | Sealed cartridge |
| Chain | KMC X9 | 9-speed | NP/NP with missing link |
| Front Derailleur | N/A |
| Rear Deralleur | Shimano Altus M2000 | 9-speed | Shadow design | direct attachment |
| Derailleur Shifter | Shimano SL-M2010 | 1 x 9-speed | Rapidfire Plus | Optical gear display |
| Pedals | VP | 990S | Nylon body with steel cages | Chromoly axles |
| Wheels | |
| Tires | Kenda Kwick Bitumen, 700 x 38c |
| Wheels/Rims | Pivit Excelsior 700c | Width (internal): 19mm | 28h | Alloy double wall | disc-brake specifc |
| Front Hub | Pivit Promenade| Double Sealed | Alloy shell | 100mm quick-release | I.S. 6-bolt disc | 28h |
| Rear Hub | Pivit Promenade| Double Sealed | Alloy shell | 135mm quick-release | I.S. 6-bolt disc | 28h | 9-speed |
| Freewheel/Cassette | Wide-range | 9-speed | 11-40T |
| Spokes | Pivit Quality Control | Stainless steel | 14G |
| Braking System | |
| Brakes | Tektro HD-T275 | Hydraulic disc | I.S. 6-bolt rotors | F: 180mm, R: 160mm |
| Brake Levers | Tektro alloy hydraulic | 3-finger |
| Other Components | |
| Grips | Pivit Entonces | Dual-density durometer | Active tuned |
| Handle Bar | Pivit Grand Assembly Bar | Alloy | 25mm rise| 31.8mm bar bore | 9° sweep | 15.5" & 17.5": 620mm; 19"-23": 640mm |
| Stem | Pivit Maverick Stem | Alloy | Positive Positioning | 7° rise | 15.5": 70mm; 17.5" & 19": 90mm; 21 & 23": 100mm |
| Seat | Haro Influencer | Dual-sport tuned padding | Weather-resistant cover |
| Seat Post | Pivit Fixed Address | Alloy | Micro-adjust positioning | 27.2mm x 350mm | Zero-offset efficiency | 2-bolt simplicity |
| Seat Clamp | Pivit Lockjaw | Alloy | 31.8mm | Multi-throw design | Quick release ease |
| Extras | Rack and fender mounts |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 70.5° | 73° | 575mm (15.5") | 394mm (15.5") | 445mm (17.5") | 60mm (2.4") | 1083mm (42.6") | 743mm (29.3") | 594mm (23.4") | 393mm (15.5") | 468mm (18.4") | 42mm (1.65") | 70mm | 620mm | 170mm |
| M | 70.5° | 73° | 585mm (17.5") | 445mm (17.5") | 445mm (17.5") | 60mm (2.4") | 1093mm (43") | 768mm (30.2") | 603mm (23.7") | 400mm (15.7") | 468mm (18.4") | 42mm (1.65") | 90mm | 620mm | 170mm |
| L | 70.5° | 73° | 600mm (19") | 483mm (19") | 445mm (17.5") | 60mm (2.4") | 1109mm (43.7") | 787mm (31") | 613mm (24.1") | 412mm (16.2") | 468mm (18.4") | 42mm (1.65") | 90mm | 640mm | 175mm |
| XL | 70.5° | 73° | 615mm (21") | 533mm (21") | 445mm (17.5") | 60mm (2.4") | 1124mm (44.3") | 815mm (32.1") | 622mm (24.5") | 424mm (16.7") | 468mm (18.4") | 42mm (1.65") | 100mm | 640mm | 175mm |
| XL+ | 70.5° | 73° | 625mm (23") | 584mm (23") | 445mm (17.5") | 60mm (2.4") | 1135mm (44.7") | 847mm (33.3") | 636mm (25") | 430mm (16.9") | 468mm (18.4") | 42mm (1.65") | 100mm | 640mm | 175mm |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
