| Frame Components |
|
| Frame |
6061-T6 aluminum | Rider-tuned geometry | 68mm BSA BB shell | Flat mount |
| Fork |
Suntour SF20 NEX HLO-DS | 63mm travel |Hydraulic Lockout | Post-mount |
| Headset |
Haro 1-1/8" threadless Internal | For 50mm OD headtube |
| Frame Shock |
N/A |
| Drivetrain |
|
| Cranks |
Prowheel TB-CY01 | 46/30T | 8-speed | 170 / 175mm |
| Bottom Bracket |
Feimin FP-902W | Threaded BSA 68mm BB shell | 123mm spindle | Sealed cartridge |
| Chain |
KMC Z8.1 | 8-speed |
| Front Derailleur |
Microshift FD-T202 | Top swing | 34.9mm band diameter |
| Rear Deralleur |
Microshift RD-M36L |
| Derailleur Shifter |
Microshift TS39-2 & FD-T202 | 2 x 8-speed |
| Pedals |
VP | 990S | Nylon body with steel cages | Chromoly axles |
| Wheels |
|
| Tires |
Kenda Kwick Bitumen | 700 x 38c |
| Wheels/Rims |
Haro 700c | 19mm inner width | 28h | Alloy double wall | Disc-brake specifc |
| Hubs |
KT-68 alloy 28H | Cassette rear hub | Front & rear quick release |
| Freewheel/Cassette |
Mid-range | CS-M5008 8-Speed 11-34T | ED Black |
| Spokes |
Stainless Steel ED Black 14G | 12MM brass nipple |
| Braking System |
|
| Brakes |
Tektro MD-M280 | Mechanical disc | IS 6-bolt rotors | F: 180mm, R: 160mm |
| Brake Levers |
Alloy 3-finger |
| Other Components |
|
| Grips |
Haro | Dual-density durometer | Active tuned |
| Handle Bar |
Haro Alloy | 25mm rise | 31.8mm x 640 / 660mm | 9° backsweep |
| Stem |
Haro Alloy | 7° rise | 70mm / 90mm / 100mm |
| Seat |
Haro | Dual-sport tuned padding | Weather-resistant cover |
| Seat Post |
Haro Alloy | Micro-Adjust | 27.2mm x 350mm | single Bolt |
| Seat Clamp |
Haro Aluminum 31.8mm Quick release |
| Extras |
Rack and fender mounts |
