Bridgeport

FEATURES

SPECIFICATIONS
Frame Components
Frame	6061-T6 aluminum \| Rider-tuned geometry \| 68mm BSA BB shell \| Flat mount
Fork	Suntour SF20 NEX HLO-DS \| 63mm travel \|Hydraulic Lockout \| Post-mount
Headset	Haro 1-1/8" threadless Internal \| For 50mm OD headtube
Frame Shock	N/A
Drivetrain
Cranks	Prowheel TB-CY01 \| 46/30T \| 8-speed \| 170 / 175mm
Bottom Bracket	Feimin FP-902W \| Threaded BSA 68mm BB shell \| 123mm spindle \| Sealed cartridge
Chain	KMC Z8.1 \| 8-speed
Front Derailleur	Microshift FD-T202 \| Top swing \| 34.9mm band diameter
Rear Deralleur	Microshift RD-M36L
Derailleur Shifter	Microshift TS39-2 & FD-T202 \| 2 x 8-speed
Pedals	VP \| 990S \| Nylon body with steel cages \| Chromoly axles
Wheels
Tires	Kenda Kwick Bitumen \| 700 x 38c
Wheels/Rims	Haro 700c \| 19mm inner width \| 28h \| Alloy double wall \| Disc-brake specifc
Hubs	KT-68 alloy 28H \| Cassette rear hub \| Front & rear quick release
Freewheel/Cassette	Mid-range \| CS-M5008 8-Speed 11-34T \| ED Black
Spokes	Stainless Steel ED Black 14G \| 12MM brass nipple
Braking System
Brakes	Tektro MD-M280 \| Mechanical disc \| IS 6-bolt rotors \| F: 180mm, R: 160mm
Brake Levers	Alloy 3-finger
Other Components
Grips	Haro \| Dual-density durometer \| Active tuned
Handle Bar	Haro Alloy \| 25mm rise \| 31.8mm x 640 / 660mm \| 9Â° backsweep
Stem	Haro Alloy \| 7Â° rise \| 70mm / 90mm / 100mm
Seat	Haro \| Dual-sport tuned padding \| Weather-resistant cover
Seat Post	Haro Alloy \| Micro-Adjust \| 27.2mm x 350mm \| single Bolt
Seat Clamp	Haro Aluminum 31.8mm Quick release
Extras	Rack and fender mounts

GEOMETRY
Size	Head Angle	Seat Angle	Top Tube (Effective)	Seat Tube (C-T)	Chainstay Length	BB Drop	Wheel Base	Stand Over	Stack Height	Reach	Fork Height	Fork Offset	Stem Length	Bar Width	Crank Length
S	70.5°	73°	575mm (15.5")	394mm (15.5")	445mm (17.5")	60mm (2.4")	1067mm (42")	743mm (29.3")	594mm (23.4")	393mm (15.5")	468mm (18.4")	42mm (1.7")	70mm	640mm	170mm
M	70.5°	73°	585mm (17.5")	445mm (17.5")	445mm (17.5")	60mm (2.4")	1078mm (42.4")	768mm (30.2")	603mm (23.7")	400mm (15.7")	468mm (18.4")	42mm (1.7")	90mm	640mm	170mm
L	70.5°	73°	600mm (19")	483mm (19")	445mm (17.5")	60mm (2.4")	1093mm (43")	787mm (31")	613mm (24.1")	412mm (16.2")	468mm (18.4")	42mm (1.7")	90mm	660mm	175mm
XL	70.5°	73°	615mm (21")	533mm (21")	445mm (17.5")	60mm (2.4")	1109mm (43.7")	815mm (32.1")	622mm (24.5")	424mm (16.7")	468mm (18.4")	42mm (1.7")	100mm	660mm	175mm
XL+	70.5°	73°	625mm (23")	584mm (23")	445mm (17.5")	60mm (2.4")	1119mm (44.1")	847mm (33.3")	636mm (25")	430mm (16.9")	468mm (18.4")	42mm (1.7")	100mm	660mm	175mm

*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
