Aeras
| Year | 2023 |
|---|---|
| MSRP | $619.99 * |
| Sizes | S, M, L, XL, XL+ |
| Colors | Matte Deep Waters |
| Weight |
Fitness has never been so fun. The Haro Aeras is lightweight, fast and as easy to ride as it is to load onto the bike rack. Built on a lightweight aluminum frame, with 700C wheels and tires, the Aeras features a 2 X 8 Microshift gearing setup for smooth, efficient pedaling, anywhere you want to go.
FEATURES
- 6061-T6 aluminum frame with rider-tuned geometry
- Microshift 2 x 8-speed gearing
- Haro 700C double wall alloy rims with quick release axles, front and rear
- Kenda Kwick 700 x 38c tires
- Haro Dual-sport tuned padded seat with micro-adjust post and quick adjust clamp
- Tecktro Mechanical Disc Brakes
| Frame Components | |
|---|---|
| Frame | 6061-T6 aluminum | Rider-tuned geometry | 68mm threaded BSA BB shell | Post mount |
| Fork | Haro Ventus | Classic steel | flat mount disc | 100mm quick-release spacing |
| Headset | Haro 1-1/8" threadless Internal | For 50mm OD headtube |
| Frame Shock | N/A |
| Drivetrain | |
| Cranks | Prowheel TB-CY01 | 46/30T | 8-speed | 170 / 175mm |
| Bottom Bracket | Feimin FP-902W | Threaded BSA 68mm BB shell | 123mm spindle | Sealed cartridge |
| Chain | KMC Z8.1 | 8-speed |
| Front Derailleur | Microshift FD-T202 | Top swing | 34.9mm band diameter |
| Rear Deralleur | Microshift RD-M36L |
| Derailleur Shifter | Microshift TS39-2 & FD-T202 | 2 x 8-speed |
| Pedals | VP | 990S | Nylon body with steel cages | Chromoly axles |
| Wheels | |
| Tires | Kenda Kwick Bitumen | 700 x 38c |
| Wheels/Rims | Haro 700c | 19mm inner width | 28h | Alloy double wall | Disc-brake specifc |
| Hubs | KT-68 alloy 28H | Cassette rear hub | Front & rear quick release |
| Freewheel/Cassette | Mid-range | CS-M5008 8-Speed 11-34T | ED Black |
| Spokes | Stainless Steel ED Black 14G | 12MM brass nipple |
| Braking System | |
| Brakes | Tektro MD-M280 | Mechanical disc | IS 6-bolt rotors | F: 180mm, R: 160mm |
| Brake Levers | Alloy 3-finger |
| Other Components | |
| Grips | Haro | Dual-density durometer | Active tuned |
| Handle Bar | Haro Alloy | 25mm rise | 31.8mm | 9° sweep | 620mm / 640mm |
| Stem | Haro Alloy | 7° rise | 70mm / 90mm / 100mm |
| Seat | Haro | Dual-sport tuned padding | Weather-resistant cover |
| Seat Post | Haro Alloy | Micro-adjust | 27.2mm x 350mm | Zero-offset | 2-bolt design |
| Seat Clamp | Haro Aluminum 31.8mm Quick release |
| Extras | Rack and fender mounts |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 70.5° | 73.5° | 555mm (21.9") | 394mm (15.5") | 445mm (17.5") | 60mm (2.4") | 1053mm (41.5") | 719mm (28.3") | 537mm (21.1") | 396mm (15.6") | 401mm (15.8") | 45mm (1.8") | 70mm | 620mm | 170mm |
| M | 70.5° | 73.5° | 570mm (22.4") | 445mm (17.5") | 445mm (17.5") | 60mm (2.4") | 1069mm (42.1") | 748mm (29.4") | 555mm (21.9") | 405mm (15.9") | 401mm (15.8") | 45mm (1.8") | 90mm | 620mm | 170mm |
| L | 71° | 73.5° | 580mm (22.8") | 483mm (19") | 445mm (17.5") | 60mm (2.4") | 1075mm (42.3") | 776mm (30.6") | 576mm (22.7") | 409mm (16.1") | 401mm (15.8") | 45mm (1.8") | 90mm | 640mm | 175mm |
| XL | 71.5° | 73° | 600mm (23.6") | 533mm (21") | 445mm (17.5") | 60mm (2.4") | 1085mm (42.7") | 814mm (32") | 607mm (23.9") | 414mm (16.3") | 401mm (15.8") | 45mm (1.8") | 100mm | 640mm | 175mm |
| XL+ | 71.5° | 73° | 620mm (24.4") | 584mm (23") | 445mm (17.5") | 60mm (2.4") | 1106mm (43.5") | 852mm (33.5") | 635mm (25") | 425mm (16.7") | 401mm (15.8") | 45mm (1.8") | 100mm | 640mm | 175mm |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
