Where does your bike take you? Sometimes it's about the destination, other times it's about how you get there. The Del Sol Soulville DLX with it's classic twin top tube steel frame was designed with both in mind. A 650b wheel-set together with a Shimano Nexus internal 3-speed drive-train, Shimano hydraulic disc brakes, color matched fenders and a front rack will push all the style, performance and cycling relaxation you can handle.
FEATURES
- D-Street Cafe twin top tube steel urban frameset
- Forged Alloy 3 Piece, bolt-on 38t chainring
- Comfort alloy handlebar with 180mm length quill stem
- Springer comfort saddle
- Double-wall Alloy rims with stainless steel spokes
- Shimano Nexus 3-spd rear hub with Shimano Revo twist shifter
- Shimano MT200 hydraulic disc brakes
- Full coverage fenders and front rack
| Frame Components | |
|---|---|
| Frame | D-Street Cafe twin top tube design, Hi-Ten steel |
| Fork | Rigid Hi-Ten, 1-1/8" threaded steerer tube |
| Headset | 1 1/8" Internal, threaded |
| Drivetrain | |
| Cranks | Forged alloy arms, bolt-on steel 38T chain ring |
| Bottom Bracket | Sealed cartridge |
| Chain | KMC S1 |
| Derailleur Shifter | Shimano Nexus Revo 3-spd |
| Pedals | Alloy body, dual compound comfort cage |
| Wheels | |
| Tires | 27.5 x 1.75" |
| Wheels/Rims | Double-wall alloy |
| Hubs | Alloy disc front, Shimano Nexus 3-speed disc rear |
| Freewheel/Cassette | Shimano 18t Cog |
| Spokes | Stainless 14g |
| Braking System | |
| Brakes | Shimano MT200 hydraulic disc |
| Brake Levers | Shimano MT200 hydraulic disc |
| Other Components | |
| Grips | Cork comfort |
| Handle Bar | Alloy, 27 degree sweeping comfort |
| Stem | Alloy, 180mm length quill |
| Seat | Springer road with rivets |
| Seat Post | Alloy micro-adjust 28.6 X 350mm |
| Seat Clamp | Alloy QR, 31.8mm |
| Extras | Fenders, chainguard, alloy kickstand, front rack |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S / 15.75 | 70.5° | 72° | 571.5mm (22.5") | 400.1mm (15.8") | 467.9mm (18.4") | 1084.8mm (42.7") | 482.6mm (19") | ||||||||
| M / 17.75 | 70.5° | 72° | 584.2mm (23") | 450.1mm (17.7") | 467.9mm (18.4") | 1100.8mm (43.3") | 514.4mm (20.3") | ||||||||
| S / 15.75 | 70.5° | 72° | 571.5mm (22.5") | 400.1mm (15.8") | 467.9mm (18.4") | 1084.8mm (42.7") | 730.3mm (28.8") | ||||||||
| M / 17.5 | 70.5° | 72° | 584.2mm (23") | 444.5mm (17.5") | 467.9mm (18.4") | 1100.8mm (43.3") | 774.7mm (30.5") | ||||||||
| L / 19 | 70.5° | 71.5° | 609.6mm (24") | 482.6mm (19") | 467.9mm (18.4") | 1117.6mm (44") | 812.8mm (32") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
