The most developed of all the LXI bikes, this 27-speed model integrates disc brakes and 29 x 2" tires into the already exclusive feel of upright comfort riding. The LXI 9.2 is perfect for riders who continue pedaling past the weekend and use their bike for the daily commute.
FEATURES
- Del Sol lightweight 6061 frame w/upright comfort geometry
- SR Suntour NEX HLO 63mm travel fork w/lock out
- Shimano 27 speed Acera drivetrain
- Adjustable angle alloy stem & lightwight alloy handlebars
- Custom Del Sol comfort plus saddle w/ suspension seatpost
- Lightweight 32 hole alloy wheelset w/ doublewall rims
- Super smooth Kenda 29 x 2" all-purpose tires
- Tektro Auriga hydraulic disc brakes
| Frame Components | |
|---|---|
| Frame | Lxi 29er Comfort 6061 oversized aluminum frame |
| Fork | SR Suntour XCT 80mm travel w/ Hydraulic Lockout |
| Headset | 1 1/8" Integrated |
| Drivetrain | |
| Cranks | Shimano M171 48/38/28t |
| Bottom Bracket | Sealed Cartridge |
| Chain | KMC X9 |
| Front Derailleur | Shimano Altus M190 |
| Rear Deralleur | Shimano Acera M390 |
| Derailleur Shifter | Shimano SL-M370 |
| Pedals | Comfort w/Kraton rubber inserts |
| Wheels | |
| Tires | Kenda Kwick Nine, 29 x 2.0" |
| Wheels/Rims | Weinmann ZAC19 alloy double wall rims, alloy disc hubs, stainless steel spokes |
| Freewheel/Cassette | Shimano HG-200 11-34T |
| Braking System | |
| Brakes | Tektro Auriga hydraulic disc, 160mm rotors |
| Brake Levers | Tektro Auriga |
| Other Components | |
| Grips | Del Sol Comfort Dual density |
| Handle Bar | Alloy riser bar, 80mm rise, 680mm width, 25.4mm clamp |
| Stem | Forged alloy quill, adjustable rise |
| Seat | Del Sol Comfort |
| Seat Post | Alloy suspension, 27.2 x 300mm |
| Seat Clamp | Alloy QR, 31.8mm |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 14 ST | 70.5° | 74° | 587mm (23.1") | 356mm (14") | 450mm (17.7") | 70mm (2.8") | 1036mm (40.8") | 627mm (24.7") | |||||||
| 17 ST | 70.5° | 74° | 597mm (23.5") | 432mm (17") | 450mm (17.7") | 70mm (2.8") | 1062mm (41.8") | 655mm (25.8") | |||||||
| 14 | 70.5° | 74° | 536mm (21.1") | 356mm (14") | 450mm (17.7") | 70mm (2.8") | 1031mm (40.6") | 777mm (30.6") | |||||||
| 17 | 70.5° | 74° | 549mm (21.6") | 406mm (16") | 450mm (17.7") | 70mm (2.8") | 1062mm (41.8") | 826mm (32.5") | |||||||
| 20 | 71° | 73° | 559mm (22") | 508mm (20") | 450mm (17.7") | 70mm (2.8") | 1069mm (42.1") | 851mm (33.5") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
