Race LT Pro XL
| Year | 2024 |
|---|---|
| MSRP | * |
| Sizes | 21" |
| Colors | Blue |
| Weight |
Full-sized and full speed ahead. The Pro XL is the biggest of the Race Lite series with a 21" top tube to fit the taller set. The 6000 series aluminum frame is low-profile with stable geometry to keep it tracking straight at the highest speeds. Chromoly forks and 8" rise bars make for a solid front end, able to handle even the harshest landings. Sealed bearings all around, a Promax disc brake and fast/grippy Kenda Konversion tires put the power to the track.
FEATURES
- 6061-T6 Heat Treated Alloy Frame w/ Integrated Headtube, Internal Cable Routing, Smooth Welding & Haro 3D Dropouts w/ Integrated Chain Tensioners. 21" top tube.
- Full chromoly 1 1/8" Threadless Steerer w/tapered legs
- 2-pc Forged 170mm alloy w/ 24mm hollow spindle. Sealed BB. 44T chainring.
- 20" Alloy 36h, double-wall rims
- 36h Alloy sealed bearing hubs w/disc 16T cassette rear
- Kenda "Konversion" 20 x 1.95" Front / 20 x 1.75" Rear
| Frame Components | |
|---|---|
| Frame | 6061-T6 Heat Treated Alloy PTC Disc Frame w/ Integrated Headtube, Internal Cable Routing, Smooth Welding & Haro 3D Dropouts w/ Integrated Chain Tensioner. 21" top tube. |
| Fork | Full chromoly 1 1/8" Threadless Steerer w/tapered legs |
| Headset | 1-1/8"" Sealed Threadless |
| Drivetrain | |
| Cranks | 2-pc Forged Alloy w/ 24mm Hollow Spindle - 175mm - 44t Alloy Chainring |
| Sprocket | 44t Alloy Chainring |
| Bottom Bracket | Press-Fit BB86, Sealed Bearing |
| Gearing | 44/16 |
| Chain | KMC Z33 12 X 3/32" |
| Pedals | Alloy DX, 9/16" |
| Wheels | |
| Tires | Kenda "Konversion" 20 x 1.95" Front / 20 x 1.75" Rear |
| Wheels/Rims | 20" Alloy 36h, Double Wall |
| Front Hub | 36h Alloy Sealed-Bearing |
| Rear Hub | Sealed Disc 16T cassette rear |
| Freewheel/Cassette | 16t Cassette |
| Spokes | 14 g |
| Braking System | |
| Brakes | Promax DSK-300 Mechanical Disc Brake w/ 160mm Rotor |
| Brake Levers | Promax XL-373 Two Finger |
| Other Components | |
| Grips | Micro-Knurl Grip |
| Handle Bar | Haro full chromoly, 8" Rise |
| Stem | Forged Alloy Top-Load, 45mm reach |
| Seat | Haro Slim Plastic Pivotal |
| Seat Post | Alloy Pivotal, 27.2mm |
| Seat Clamp | Alloy, 31.8mm |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 20 | 74° | 72° | 533mm (21") | 240mm (9.4") | 387mm (15.2") | 293mm (11.5") | 562mm (22.1") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
