When you can't stand not to know what's around the next bend, grab your Westlake. Go further and see more with 63mm of front suspension travel, powerful hydraulic disc brakes, an elevation-conquering Shimano 24 speed drivetrain and fast-rolling, durable Kenda tires.
FEATURES
- Haro Solum Dual Sport frame with Rider Optimized Geometry, mechanically-shaped alloy tubing, and chainstay disc brake mount
- SR Suntour NEX HLO suspension fork with 63mm travel and hydraulic lockout
- Shimano TY-501 48/38/28t crankset w/ sealed cartridge BB
- Shimano Altus 8 speed shifters, front and rear derailleurs
- New MY17 Shimano M315 hydraulic disc brakes
- Pivit disc brake hubs w/ Alex DC-26 700c double wall rims
- Pivit alloy 25mm riser bar and forged stem
- Kenda Bitumen 700 x 38c tires
- VP nylon body pedals w/ steel cages
| Frame Components | |
|---|---|
| Frame | Haro Solum 6061 Alloy w/ Rider-Tuned Geometry |
| Fork | SR Suntour NEX HLO 63mm travel w/ Hydraulic Lockout |
| Headset | FSA Orbit No. 10 |
| Frame Shock | N/A |
| Drivetrain | |
| Cranks | Shimano TY-501 48/38/28t |
| Bottom Bracket | Shimano Sealed Cartridge |
| Chain | KMC X8 |
| Front Derailleur | Shimano Altus M191 |
| Rear Deralleur | Shimano Altus M310 |
| Derailleur Shifter | Shimano SL-M310 3x8-Spd |
| Pedals | VP Nylon Body w/ Steel Cages |
| Wheels | |
| Tires | Kenda Kwick Bitumen 700 x 38c |
| Wheels/Rims | Alex DC-26 700c Alloy DW 32h Rims, Pivit Alloy Disc Cassette Hubs |
| Freewheel/Cassette | Shimano HG-200-8 8-Spd 12-32t |
| Braking System | |
| Brakes | 2017 Shimano BR-M315 Hydraulic |
| Brake Levers | 2017 Shimano BL-M315 2-3 Fingers |
| Other Components | |
| Grips | Haro Dual Sport |
| Handle Bar | Pivit Alloy 25mm Rise 31.8mm 9° Sweep |
| Stem | Pivit Alloy, 31.8mm |
| Seat | Haro Dual Sport |
| Seat Post | Pivit Alloy Micro Adjust 27.2mm |
| Seat Clamp | Alloy Q/R, 31.8mm |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 15.5 | 70.5° | 73° | 575mm (22.6") | 394mm (15.5") | 445mm (17.5") | 1067mm (42") | 700mm (27.6") | ||||||||
| 17.5 | 70.5° | 73° | 585mm (23") | 445mm (17.5") | 445mm (17.5") | 1078mm (42.4") | 725mm (28.5") | ||||||||
| 19 | 70.5° | 73° | 600mm (23.6") | 483mm (19") | 445mm (17.5") | 1093mm (43") | 748mm (29.4") | ||||||||
| 21 | 70.5° | 73° | 615mm (24.2") | 533mm (21") | 445mm (17.5") | 1108mm (43.6") | 794mm (31.3") | ||||||||
| 23 | 70.5° | 73° | 625mm (24.6") | 584mm (23") | 445mm (17.5") | 1119mm (44.1") | 843mm (33.2") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
