Soulville

Year 2019
MSRP $469.99 *
Sizes S, M, L
Colors SG Black, Limpet Shell
Weight

FEATURES

  • Custom D-Street steel urban frameset
  • Shimano Altus 1x8 drivetrain
  • Del Sol alloy crankset
  • Tektro Aires mechanical disc brakes
  • Custom alloy 31.8mm Soulville handlebar
  • Fast-rolling and durable 27.5x1.75 tires
  • Sturdy 32-hole alloy wheelset with doublewall rims
  • Color-matched full-coverage fenders
SPECIFICATIONS
Frame Components
Frame D-Street Café 27.5x1.75" Steel
Fork Rigid Hi-Ten
Headset 1 1/8" Loose Ball
Drivetrain
Cranks Forged Alloy 3 Piece, 38t
Bottom Bracket Sealed Cartridge
Chain KMC Z8
Front Derailleur N/A
Rear Deralleur Shimano Altus RDM310
Derailleur Shifter Shimano Altus, 8-spd
Pedals D-Street Comfort
Wheels
Tires 27.5x1.75"
Wheels/Rims 27.5" Double-Wall Alloy
Hubs Alloy Disc, 32H
Freewheel/Cassette Shimano Altus, 11-34t 8-spd
Braking System
Brakes Tektro Aires Mechanical Disc
Brake Levers Alloy
Other Components
Grips Cork Comfort
Handle Bar D-Street Soulville AL
Stem Alloy Quill, Adjustable Angle/Rise
Seat D-Street Comfort
Seat Post Alloy micro-adjust 27.2 X 350mm
Seat Clamp Alloy QR, 31.8mm
Extras Fenders, Kickstand, Rack mounts
GEOMETRY
Size Head Angle Seat Angle Top Tube (Effective) Seat Tube (C-T) Chainstay Length BB Drop Wheel Base Stand Over Stack Height Reach Fork Height Fork Offset Stem Length Bar Width Crank Length
S ST 70.5° 72° 572mm (22.5") 381mm (15") 439mm (17.3") 1077mm (42.4") 533mm (21")
M ST 70.5° 72° 587mm (23.1") 429mm (16.9") 439mm (17.3") 1092mm (43") 544mm (21.4")
S 70.5° 72° 572mm (22.5") 406mm (16") 439mm (17.3") 1077mm (42.4") 757mm (29.8")
M 70.5° 72° 587mm (23.1") 445mm (17.5") 439mm (17.3") 1092mm (43") 762mm (30")
L 70.5° 71.5° 610mm (24") 485mm (19.1") 439mm (17.3") 1110mm (43.7") 800mm (31.5")

RESOURCES

Owner's manual: Bike Manual PDF

*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
