FEATURES
- All-new LXI Flow lightweight aluminum frame with new Size Specific Wheel design
- SR Suntour NEX HLO DS 63mm travel fork w/lock out
- Wide-range 1x9 drivetrain featuring Alivio M4000 rear derailleur
- Powerful Shimano hydraulic disc brakes ensure all-condition stopping power
- Adjustable-angle alloy stem and lightweight alloy riser bars mean you find the perfect fit, no matter the rider
- Custom Del Sol comfort plus saddle with suspension seatpost
| Frame Components | |
|---|---|
| Frame | New LXI Flow SSW (Size-Specific Wheel) Comfort 6061 Alloy |
| Fork | SR Suntour Nex HLO DS 63mm Travel w/ Hydraulic Lockout |
| Headset | 1 1/8" Integrated |
| Drivetrain | |
| Cranks | LXI Flow+ 1x crankset, 38t |
| Bottom Bracket | Sealed Cartridge |
| Chain | KMC X9 |
| Front Derailleur | N/A |
| Rear Deralleur | Shimano Alivio M4000 |
| Derailleur Shifter | Shimano Altus M2000 Rapidfire+ |
| Pedals | Nylon Comfort w/Kraton |
| Wheels | |
| Tires | Comfort Hybrid -- 26 x 1.75" (14" frame), 27.5 x 1.75" (17" frame), 29 x 1.75" (20" frame) |
| Wheels/Rims | Double-Wall Alloy |
| Hubs | Shimano CenterLock Disc, 32H |
| Freewheel/Cassette | Sunrace 11-36t 9spd |
| Braking System | |
| Brakes | Shimano MT200 Hydraulic Disc |
| Brake Levers | Shimano MT200 Hydraulic Disc |
| Other Components | |
| Grips | Del Sol Comfort Dual Density |
| Handle Bar | Alloy Riser Bar, 80mm Rise, 680mm Width |
| Stem | Alloy Quill, Adjustable Rise |
| Seat | Del Sol Comfort Springer |
| Seat Post | Alloy Suspension, 27.2 X 300mm |
| Seat Clamp | Alloy QR, 31.8mm |
| Extras | Rack & Fender Mounts |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S ST | 70.5° | 74° | 572mm (22.5") | 356mm (14") | 439mm (17.3") | 1036mm (40.8") | 625mm (24.6") | ||||||||
| M ST | 70.5° | 74° | 584mm (23") | 432mm (17") | 450mm (17.7") | 1062mm (41.8") | 638mm (25.1") | ||||||||
| S 14 | 70.5° | 74° | 572mm (22.5") | 356mm (14") | 439mm (17.3") | 1031mm (40.6") | 673mm (26.5") | ||||||||
| M 17 | 70.5° | 74° | 584mm (23") | 432mm (17") | 450mm (17.7") | 1062mm (41.8") | 701mm (27.6") | ||||||||
| L 20 | 71° | 73° | 592mm (23.3") | 508mm (20") | 470mm (18.5") | 1069mm (42.1") | 737mm (29") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
