This is the campus radio station of bikes, genre bending and category defying. The D Street Project 24 sports a light 6000 series aluminum frame with a Step Thru option and is rack and fender ready. It has extra gears to make you go faster, and Tektro mechanical discs to slow you down especially in wet weather. 32-hole double wall rims and alloy hubs are connected with rust free 14g stainless steel spokes. Shimano’s EZ Fire shifters make swift work of its 24-speed drive train making D Street Projekt 24 one of the most versatile and affordable bikes on the market.
FEATURES
- Custom D-Street 6000 series alloy City Cafe frameset with Step-Thru option and rack and fender mounts
- Shimano 24-speed Altus derailleurs with EZ Fire shifters
- Shimano TY301 alloy 3pc crankset
- Tektro MD-280 mechanical disc brakes
- Lightweight alloy oversize 31.8mm handlebar & stem
- Fast-rolling and durable Kenda 700x35c tires
- Sturdy 32-hole alloy wheelset with double wall rims
- Alloy linear pull brakeset
- Alloy micro-adjust seatpost
| Frame Components | |
|---|---|
| Frame | D-Street 6061 Alloy Disc |
| Fork | Rigid Hi-Ten Disc |
| Headset | 1 1/8" Threadless |
| Drivetrain | |
| Cranks | Shimano TY301 48/38/28t |
| Bottom Bracket | Sealed Cartridge |
| Chain | KMC Z51 |
| Front Derailleur | Shimano Tourney TY191 |
| Rear Deralleur | Shimano Altus M310 |
| Derailleur Shifter | Shimano EF51 |
| Pedals | Wellgo Nylon Body |
| Wheels | |
| Tires | Kenda 700x35mm |
| Wheels/Rims | Double-Wall Alloy |
| Hubs | Alloy Disc, 32H |
| Freewheel/Cassette | Shimano HG-31 11-32t 8-spd |
| Braking System | |
| Brakes | Shimano EF51 |
| Brake Levers | Tektro MD-280 Mechanical Disc |
| Other Components | |
| Grips | D Street Commuter |
| Handle Bar | Alloy Oversize Riser Bar, 35mm Rise, 680mm Width |
| Stem | Forged Alloy, 7 Degree Rise |
| Seat | D-Street Padded Retro |
| Seat Post | Alloy Micro Adjust, 27.2 X 350mm |
| Seat Clamp | Alloy Single Bolt |
| Extras | Rack & Fender Mounts |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS / 14 ST | 70.5° | 74° | 546mm (21.5") | 356mm (14") | 450mm (17.7") | 1041mm (41") | 625mm (24.6") | 90mm | 680mm | 170mm | |||||
| S / 16 ST | 71° | 73° | 564mm (22.2") | 432mm (17") | 450mm (17.7") | 1049mm (41.3") | 638mm (25.1") | 90mm | 680mm | 170mm | |||||
| XS / 14 | 70.5° | 74° | 546mm (21.5") | 356mm (14") | 450mm (17.7") | 1049mm (41.3") | 673mm (26.5") | 90mm | 680mm | 170mm | |||||
| S / 16 | 70.5° | 74° | 551mm (21.7") | 406mm (16") | 450mm (17.7") | 1054mm (41.5") | 686mm (27") | 90mm | 680mm | 170mm | |||||
| M / 18 | 71° | 73° | 564mm (22.2") | 711mm (28") | 450mm (17.7") | 1054mm (41.5") | 711mm (28") | 105mm | 680mm | 170mm | |||||
| L / 20 | 71° | 73° | 584mm (23") | 508mm (20") | 450mm (17.7") | 1074mm (42.3") | 737mm (29") | 105mm | 680mm | 175mm | |||||
| XL / 22 | 72.2° | 73° | 599mm (23.6") | 559mm (22") | 450mm (17.7") | 1074mm (42.3") | 762mm (30") | 105mm | 680mm | 175mm |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
