Projekt
| Year | 2017 |
|---|---|
| MSRP | $329.99 * |
| Sizes | XS, S, M, L, XL |
| Colors | Teal, Brick Red, Black |
| Weight |
One speed is a movement, a cult, a state of mind. With only one speed, there is nothing between you and your bicycle. Simple as running, freeing as flying, you become the ultimate pedal-powered steam-punk beast: two wheels, two legs, two parallel spines of bone and steel. Get one-on-one with your Projekt: a keepin' it real steel frame, alloy bars, stainless steel spokes, a rear brake for emergencies (and to keep it legal) and the thoughtful addition of a flip flop-hub for switching from fixed to freewheel. It's an uncompromising vision, and a powerfully vivid way to crank through the city.
FEATURES
- Custom D-Street hi ten urban frameset
- Alloy 3-piece crankset with sealed BB
- Simple one speed freewheel drivetrain
- Tektro R317 rear brake
- Kenda 700 x 28c tires
- Sturdy 32 hole alloy wheelset with doublewall rims
| Frame Components | |
|---|---|
| Frame | D-Street Hi-Ten Singlespeed Frame W/Track Dropouts |
| Fork | Rigid Hi-Ten |
| Headset | 1 1/8" Threadless |
| Drivetrain | |
| Cranks | Forged Alloy 3 Piece, 42t |
| Bottom Bracket | Sealed Cartridge |
| Chain | KMC Z410 |
| Front Derailleur | N/A |
| Rear Deralleur | N/A |
| Derailleur Shifter | N/A |
| Pedals | Wellgo Nylon Body |
| Wheels | |
| Tires | Kenda K176, 700 X 28c |
| Wheels/Rims | DH18 alloy double wall rims, alloy hubs, stainless steel spokes |
| Freewheel/Cassette | 16t Freewheel |
| Braking System | |
| Brakes | Alloy linear pull |
| Brake Levers | Alloy linear pull |
| Other Components | |
| Grips | Projekt Bmx Style |
| Handle Bar | Steel Riser Bar, 30mm Rise, 600mm Width, 25.4mm Clamp |
| Stem | Forged Alloy, 10 Degree Rise |
| Seat | D-Street Padded Retro |
| Seat Post | Steel 25.4mm X 250mm |
| Seat Clamp | Alloy Single Bolt |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 70° | 74.5° | 533mm (21") | 490mm (19.3") | 424mm (16.7") | 70mm (2.8") | 1019mm (40.1") | 757mm (29.8") | |||||||
| S | 70.5° | 74° | 541mm (21.3") | 521mm (20.5") | 424mm (16.7") | 70mm (2.8") | 1024mm (40.3") | 775mm (30.5") | |||||||
| M | 71° | 74° | 556mm (21.9") | 551mm (21.7") | 424mm (16.7") | 70mm (2.8") | 1034mm (40.7") | 803mm (31.6") | |||||||
| L | 72° | 74° | 574mm (22.6") | 579mm (22.8") | 424mm (16.7") | 70mm (2.8") | 1044mm (41.1") | 833mm (32.8") | |||||||
| XL | 72° | 73° | 594mm (23.4") | 610mm (24") | 424mm (16.7") | 70mm (2.8") | 1062mm (41.8") | 856mm (33.7") | |||||||
| XS | 70° | 74.5° | 533mm (21") | 490mm (19.3") | 423mm (16.7") | 1018mm (40.1") | 29.8mm (1.2") | ||||||||
| S | 70.5° | 74° | 542mm (21.3") | 520mm (20.5") | 423mm (16.7") | 1023mm (40.3") | 30.5mm (1.2") | ||||||||
| M | 71° | 74° | 556mm (21.9") | 550mm (21.7") | 423mm (16.7") | 1034mm (40.7") | 31.6mm (1.2") | ||||||||
| L | 72° | 74° | 575mm (22.6") | 580mm (22.8") | 423mm (16.7") | 1045mm (41.1") | 32.8mm (1.3") | ||||||||
| XL | 72° | 73° | 595mm (23.4") | 610mm (24") | 423mm (16.7") | 1061mm (41.8") | 33.7mm (1.3") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
