Comfortable, upright and versatile, the 26"-wheeled LXi 6.1 will handle your neighborhood roads with aplomb. The heart of your smooth ride is our high quality LXi 6061 aluminum frame, paired with a 50 mm suspension fork. It's all gain and no pain with the Del Sol comfort saddle and suspension seat post, Del Sol comfort grips and adjustable stem.
FEATURES
- Del Sol lightweight 6061 frame with upright comfort geometry
- Ultra-compliant 50mm travel suspension fork
- Shimano 21 speed Tourney derailleurs with Revo twist shifters
- Adjustable angle alloy stem and lightweight steel handlebars
- Custom Del Sol comfort plus saddle with suspension seatpost
- Lightweight 32 hole alloy wheelset with doublewall rims
- Smooth rolling 26" all-purpose tires
| Frame Components | |
|---|---|
| Frame | Lxi 26" Comfort 6061 oversized aluminum frame |
| Fork | Del Sol 420-E, 50mm travel |
| Headset | 1 1/8" Integrated |
| Drivetrain | |
| Cranks | SR Suntour XCC 172, 42/32/22t |
| Bottom Bracket | Sealed Cartridge |
| Chain | KMC Z51 |
| Front Derailleur | Shimano Tourney TY500 |
| Rear Deralleur | Shimano Tourney TY300D |
| Derailleur Shifter | Shimano Revo |
| Pedals | Comfort w/Kraton rubber inserts |
| Wheels | |
| Tires | 26 x 1.95" Comfort |
| Wheels/Rims | DH18 alloy double wall rims, alloy hubs, stainless steel spokes |
| Freewheel/Cassette | Shimano HG-20 12-32t |
| Braking System | |
| Brakes | Alloy linear pull |
| Brake Levers | Alloy linear pull |
| Other Components | |
| Grips | Del Sol Comfort Dual density |
| Handle Bar | Steel riser bar, 80mm rise, 680mm width, 25.4mm clamp |
| Stem | Forged alloy quill, adjustable rise |
| Seat | Del Sol Comfort |
| Seat Post | Alloy suspension, 27.2 x 300mm |
| Seat Clamp | Alloy QR, 31.8mm |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 17 | 70.5° | 72.5° | 537mm (21.1") | 432mm (17") | 437mm (17.2") | 70mm (2.8") | 1062mm (41.8") | 737mm (29") | |||||||
| 14 | 70.5° | 72.5° | 523mm (20.6") | 356mm (14") | 437mm (17.2") | 70mm (2.8") | 1036mm (40.8") | 681mm (26.8") | |||||||
| 17 ST ST | 70.5° | 72.5° | 579mm (22.8") | 432mm (17") | 437mm (17.2") | 70mm (2.8") | 1062mm (41.8") | 658mm (25.9") | |||||||
| 14 ST ST | 70.5° | 72.5° | 561mm (22.1") | 356mm (14") | 437mm (17.2") | 70mm (2.8") | 1041mm (41") | 648mm (25.5") | |||||||
| 20 | 70.5° | 72.5° | 559mm (22") | 508mm (20") | 437mm (17.2") | 70mm (2.8") | 1069mm (42.1") | 762mm (30") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
