Plaza
- Year: 2015
- MSRP: $619.99 *
- Sizes: 20.5", 21"
- Colors: Matte Black, SG Dark Blue
- Weight: 24 lbs
- NO LONGER AVAILABLE
FEATURES
- 100% chromoly frame with butted top tube, Mid BB shell, integrated head tube, welded seat clamp, 20.5" or 21" top tube length and removable brake and cable mounts
- 100% chromoly fork with internal threaded steer tube and tapered legs
- 100% chromoly bars 8.50" (on 20.5") or 8.75" (on 21") with Haro Lineage CNC alloy front load stem
- 2-piece chromoly 8-spline 175mm cranks with Haro Lineage 28T CNC alloy sprocket and sealed Mid BB
- 28/9 gearing
- Fully sealed wheels with Haro double-wall alloy rims and female front axle hub
- Haro La Mesa tires 2.4" front and rear
- Haro padded Tri-pod seat with alloy Tri-pod post
- Haro "Recycled" plastic pedals
- Haro Team grips
- KMC K710SL super light chain
Frame Components | |
---|---|
Frame | Full crmo frame w/removable brake mounts - 20.5 or 21" TT |
Fork | Full Crmo w/ CNC 1 piece steer tube and tapered legs |
Drivetrain | |
Cranks | 2 pc. tubular Crmo 175mm w/sealed 19mm MID BB |
Gearing | 28/9 w/Sealed Bearing Cassette One Piece Driver |
Pedals | Haro "Recycled" plastic pedal |
Wheels | |
Tires | Haro La Mesa 20x2.40 F / R |
Wheels/Rims | Haro 36H Alloy double wall front and rear |
Hubs | 36H Alloy sealed bearing 3/8" female Frt/14mm Rr axle |
Braking System | |
Rotor | Straight Cable |
Other Components | |
Grips | Haro Team Grips |
Handle Bar | Full Crmo 8.50" rise w/20.5" frame, 8.75" rise w/21" frame |
Seat | Haro Tri-pod padded seat w/alloy Tri-pod post |
Pegs | N/A |
Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
---|---|---|---|---|---|---|---|
20.5 | 75° | 71.5° | 520mm (20.5") | 260mm (10.2") | 349mm (13.7") | 293mm (11.5") | 546mm (21.5") |
21 | 75° | 71.5° | 533mm (21") | 260mm (10.2") | 349mm (13.7") | 293mm (11.5") | 546mm (21.5") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
