FEATURES
- Full hi-ten frame with welded seat clamp and 18.5" or 20.3" top tube
- Full hi-ten fork with tapered legs
- Hi-ten bars 7.50" (on 18.5") or 8.25" (on 20.3") with Haro alloy front load stem
- 3-piece chromoly 8-spline 165mm (on 18.5") or 175mm (on 20.3") cranks with loose ball USA BB
- 25/9 gearing
- Kenda Kontact tires 2.25" front and rear
- Haro padded fully adjustable seat
- Haro Team grips
| Frame Components | |
|---|---|
| Frame | Full Hi-Ten frame - 18.5 or 20.3" TT |
| Fork | 1 1/8" Hi-Ten threadless w/ tapered legs |
| Drivetrain | |
| Cranks | 3 pc. tubular Crmo 165 / 175mm w/loose ball USA BB |
| Gearing | 25/9 w/cassette 9T driver |
| Pedals | Wellgo plastic pedal |
| Wheels | |
| Tires | Kenda Kontact 20x2.25 F / R |
| Wheels/Rims | 36H Alloy single wall |
| Hubs | 36H steel shell 3/8" Frt/Alloy shell cassette rear 14mm |
| Braking System | |
| Rotor | Straight Cable |
| Other Components | |
| Grips | Haro Team Grips |
| Handle Bar | Hi-Ten 7.50" or 8.25" rise |
| Seat | Haro padded adjustable seat w/ rails and steel post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 18.5 | 74.5° | 70° | 470mm (18.5") | 250mm (9.8") | 349mm (13.7") | 293mm (11.5") | 546mm (21.5") |
| 20.3 | 74.5° | 70° | 516mm (20.3") | 250mm (9.8") | 349mm (13.7") | 293mm (11.5") | 546mm (21.5") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
