FEATURES
- 3 tube chromoly frame (top tube, down tube & seat tube) with mid BB shell, integrated head tube, welded seat clamp and a 20.5" or 21" top tube length
- Internal threaded chromoly steer tube fork with hi-ten tapered legs
- Hi-ten bars 8.50" (on 20.5") or 8.75" (on 21") with Haro alloy front load stem
- 3-piece chromoly 8-spline 175mm cranks with steel 25T sprocket and sealed Mid
- 25/9 gearing
- Fully sealed wheels with Haro single-wall alloy rims
- Haro La Mesa tires 2.4" front and rear
- Haro padded Tri-pod seat with alloy Tri-pod post
- Haro "Recycled" plastic pedals
- Haro Team grips
| Frame Components | |
|---|---|
| Frame | Crmo TT/DT/ST, w/Integrated HT and MID BB - 20.5 or 21" TT |
| Fork | Internal threaded crmo steer tube w/ hi-ten taper legs |
| Drivetrain | |
| Cranks | 3 pc. tubular Crmo 175mm w/sealed MID BB |
| Gearing | 25/9 w/cassette 9T driver |
| Pedals | Haro "Recycled" plastic pedal |
| Wheels | |
| Tires | Haro La Mesa 20x2.40 F / R |
| Wheels/Rims | Haro 36H Alloy single wall front and rear |
| Hubs | 36H Alloy sealed bearing, 3/8" Frt/14mm Rr axle |
| Braking System | |
| Rotor | Straight Cable |
| Other Components | |
| Grips | Haro Team Grips |
| Handle Bar | Hi-Ten 8.50" rise w/20.5" frame, 8.75" rise w/21" frame |
| Seat | Haro Tri-pod padded seat w/alloy Tri-pod post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 20.5 | 75° | 71.5° | 520mm (20.5") | 250mm (9.8") | 349mm (13.7") | 293mm (11.5") | 546mm (21.5") |
| 21 | 75° | 71.5° | 533mm (21") | 250mm (9.8") | 349mm (13.7") | 293mm (11.5") | 546mm (21.5") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
