FST 24
| Year | 2015 |
|---|---|
| MSRP | $1,089.99 * |
| Sizes | 21.75" |
| Colors | Gloss Bright Red |
| Weight |
FEATURES
- 100% chromoly frame with Mid BB shell, integrated head tube and 21.75" top tube length
- 100% chromoly fork with internal threaded steer tube and tapered legs
- 100% chromoly 7" Freestyler bars with Haro Lineage CNC alloy top load stem
- Lineage 3-piece chromoly 48-spline 175mm cranks with Haro CNC alloy Uni-directional sprocket/spider combo and sealed Mid BB
- 41/17 gearing
- Fully sealed 24" Skyway Tuff wheels with alloy flange hubs
- Kenda Kranium tires 24x2.1" front and rear
- Haro "1978" padded Tri-pod seat with alloy Tri-pod fluted post
- Haro "Recycled" plastic pedals
- Haro Team grips
- Dia-Compe FS996 brakes with Tech 77 lever
- 100 models produced
| Frame Components | |
|---|---|
| Frame | Full Crmo, internal HT & Mid BB - 21.75" TT |
| Fork | Full Crmo w/ internal threaded steer tube and tapered legs |
| Drivetrain | |
| Cranks | Lineage Crmo 48 spline 175mm w/ Mid sealed bearing BB |
| Gearing | 41/17 |
| Pedals | Haro "Recycled" plastic |
| Wheels | |
| Tires | Kenda Kranium 24x2.10 F/R |
| Wheels/Rims | Skyway 24" Tuff Wheels |
| Hubs | 3/8" F/R; Skyway 24" Tuff Wheels with alloy flanges |
| Braking System | |
| Rotor | N/A - straight cable |
| Other Components | |
| Grips | Haro Team Grip |
| Handle Bar | Crmo 7" rise / Lineage CNC Alloy top load stem |
| Seat | Padded Tri-pod seat with alloy Tri-pod post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 21.65 | 73° | 70° | 550mm (21.65") | 320mm (12.6") | 418mm (16.5") | 315mm (12.4") | 635mm (25") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
