FEATURES
- 6061 series alloy frame with integrated head tube, 3D dropouts with integrated chain tensioners and 16.75" top tube
- 100% chromoly 1" threadless fork
- Mini alloy bars and Haro CNC alloy front load stem
- 3-piece 130mm alloy race cranks with sealed Euro BB
- 28-spoke sealed wheels with 18" Alienation Ankle Biter rims, 14t cassette rear hub and alloy nipples
- Vee Rubber Speedster tires, 18 x 1"
- Velo Unibody seat with built-in alloy post
- Alloy V-Brake
| Frame Components | |
|---|---|
| Frame | 6061 Alloy with integrated head tube -16.75" TT |
| Fork | Full Crmo 1" Threadless |
| Drivetrain | |
| Cranks | 3pc Alloy race 130mm / Sealed bearing Euro BB |
| Gearing | 38/14 |
| Pedals | Mini DX Alloy |
| Wheels | |
| Tires | Vee Rubber "Speedster" 18x1" |
| Wheels/Rims | Alienation Ankle Biter alloy 28H 18" |
| Hubs | 28h Alloy Shell sealed bearing; 28h Alloy Shell sealed bearing cassette |
| Braking System | |
| Rotor | N/A |
| Brakes | Alloy V-brake - rear only |
| Brake Levers | Alloy Lever |
| Other Components | |
| Grips | Velo Mini Knurled Grips |
| Handle Bar | Mini Alloy Bar / Haro CNC Alloy front load 45mm ext |
| Seat | Velo Unibody w/Alloy Post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 16.75 | 72° | 71.47° | 425.4mm (16.75") | 180mm (7.1") | 300mm (11.8") | 222.2mm (8.75") | 393.7mm (15.5") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
