FEATURES
- 6061 series alloy frame with integrated head tube, butted down tube, tapered chain stays, 3D dropouts with integrated chain tensioners and 18.25" top tube
- 100% chromoly 1" threadless fork
- Junior 5" rise alloy bars and Haro CNC alloy front load stem
- 3-piece 155mm alloy race cranks with sealed Euro BB
- 28-spoke sealed wheels with 20" Alienation Ankle Biter rims, 14t cassette rear hub and alloy nipples
- Kenda Kompact 20x1-1/8" tires
- Velo Unibody seat with built-in alloy post
- Promax V-Brake and lever
| Frame Components | |
|---|---|
| Frame | 6061 alloy with integrated head tube -18.25" TT. |
| Fork | Full Crmo 1" Threadless |
| Drivetrain | |
| Cranks | 3pc Alloy race 155mm / Sealed bearing Euro BB |
| Gearing | 36/14 |
| Pedals | Mini DX Alloy |
| Wheels | |
| Tires | Kenda "Kompact" K1054 20x1 1/8" |
| Wheels/Rims | Alienation Ankle Biter alloy 28H |
| Hubs | 28h Alloy Shell sealed bearing; 28h Alloy Shell sealed bearing cassette |
| Braking System | |
| Rotor | N/A |
| Brakes | Promax MV-85 Alloy V-brake - rear only |
| Brake Levers | Promax XL-373 Alloy Lever |
| Other Components | |
| Grips | Velo Mini Knurled Grips |
| Handle Bar | Alloy 5" rise / Haro CNC Alloy front load 45mm ext |
| Seat | Velo Unibody w/Alloy Post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 18.3 | 73° | 71° | 464.9mm (18.3") | 232.7mm (9.2") | 346mm (13.6") | 280mm (11") | 495.3mm (19.5") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
