FEATURES
- Premium 20.75" brakeless frame with integrated head tube, Mid BB shell, crmo down tube and built in cut-away pivotal mount
- Internal threaded crmo steer tube fork with hi-ten tapered legs
- 8.75" rise bar with Premium alloy front load stem
- Three-piece crmo 175mm 8-spline cranks with sealed Mid BB
- 25/9 gearing
- Alienation PBR rims
- Premium CK tires 2.4" front and rear
- Premium Fat Capitol seat
- Premium loose ball plastic pedals
- Caliper brake included
| Frame Components | |
|---|---|
| Frame | Crmo down tube brakeless frame w/ integrated Pivotal post - 20.75" TT |
| Fork | Crmo internal threaded steer tube w/Hi-ten tapered legs |
| Drivetrain | |
| Cranks | 3 pc. tubular Crmo 175mm w/sealed MID BB |
| Gearing | 25/9 w/ one piece 9T driver |
| Pedals | Premium plastic pedals |
| Wheels | |
| Tires | Premium CK 20x2.40 front and rear |
| Wheels/Rims | 36h Alienation PBR alloy SW front and rear |
| Hubs | 36h alloy shell 3/8" Frt / Alloy shell loose ball 14mm rear w/9T driver |
| Braking System | |
| Rotor | N/A - Straight Cable and caliper brake included |
| Other Components | |
| Grips | Premium Counterfeit |
| Handle Bar | Hi-ten - 8.75" rise |
| Seat | Premium Fat Capitol Pivotal seat |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 20.75 | 75° | 71.5° | 527mm (20.75") | 275mm (10.8") | 349mm (13.7") | 293mm (11.5") | 540mm (21.3") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
