FEATURES
- Full hi-ten frame with internal head tube, Mid BB shell and 20.5" top tube
- Full hi-ten fork with tapered legs
- Hi-ten 8.50" bars with Premium alloy front load stem
- 3-piece chromoly 8-spline 175mm cranks with sealed Mid BB
- 25/9 gearing
- Premium CK tires 2.4" front and rear
- Premium padded one piece seat with built-in alloy post
- Premium Counterfeit grips
| Frame Components | |
|---|---|
| Frame | Full Hi-ten w/ Integrated HT and MID BB - 20.5" TT |
| Fork | Hi-ten threadless steer tube w/ tapered legs |
| Drivetrain | |
| Cranks | 3 pc. tubular Crmo 175mm w/sealed MID BB |
| Gearing | 25/9 w/one piece 9T driver |
| Pedals | Premium plastic pedals |
| Wheels | |
| Tires | Premium CK 20x2.40 front and rear |
| Wheels/Rims | 36h alloy SW front and rear |
| Hubs | 36h steel shell 3/8" Frt / Alloy shell loose ball 14mm rear w/9T driver |
| Braking System | |
| Rotor | N/A Straight Cable |
| Other Components | |
| Grips | Premium Counterfeit |
| Handle Bar | Hi-ten - 8.50" rise |
| Seat | Premium padded one piece seat with built in post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 20.5 | 75° | 72° | 520mm (20.5") | 260mm (10.2") | 349mm (13.7") | 293mm (11.5") | 560mm (22") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
