FEATURES
| Frame Components | |
|---|---|
| Frame | Flightline FL3G 20" 6061 T6 oversized aluminum |
| Fork | Haro 410-E, 30mm travel |
| Headset | Steel threadless |
| Drivetrain | |
| Cranks | Forged alloy w/ 40t chainring and double guard |
| Bottom Bracket | Square taper |
| Chain | KMC Z33 |
| Front Derailleur | N/A |
| Rear Deralleur | Shimano TZ-50 |
| Derailleur Shifter | Shimano Revo, 6 speed |
| Pedals | Nylon ATB |
| Wheels | |
| Tires | H-5120, 20 x 1.95" |
| Wheels/Rims | C-20 32h rims, Pivit steel hubs, stainless steel spokes |
| Freewheel/Cassette | Shimano MF-TZ20, 6 speed freewheel, 14-28 |
| Braking System | |
| Brakes | Alloy direct pull w/ linear spring |
| Brake Levers | Promax BL-42G |
| Other Components | |
| Grips | Dual density |
| Handle Bar | Pivit riser bar, 30mm rise, 580mm width |
| Stem | Pivit alloy, 15 degree rise |
| Seat | Haro Junior |
| Seat Post | Pivit alloy micro adjust, 27.2 x 250mm |
| Seat Clamp | Pivit alloy 31.8 quick release |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 20 | 70° | 71° | 469mm (18.5") | 260mm (10.2") | 363mm (14.3") | 0mm (0") | 888mm (35") | 557mm (21.9") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
