FEATURES
| Frame Components | |
|---|---|
| Frame | Dual Sport 6061 T6 oversized aluminum w/ semi-integrated headtube |
| Fork | SR Suntour NEX, 63mm travel w/ hydraulic lock out |
| Headset | FSA # 10 semi-integrated |
| Drivetrain | |
| Cranks | SR Suntour XCC 208, 48/38/28 |
| Bottom Bracket | Sealed cartridge |
| Chain | KMC Z51 |
| Front Derailleur | Shimano TX-51 |
| Rear Deralleur | Shimano TX-35 |
| Derailleur Shifter | Shimano EF-41 EZ Fire, 7 speed |
| Pedals | Nylon |
| Wheels | |
| Tires | H-5113, 700 x 38c |
| Wheels/Rims | Weinmann ZAC-19 32h rims, Pivit alloy disc cassette hubs, stainless steel spokes |
| Freewheel/Cassette | Shimano HG-20, 7 speed cassette, 12-32 |
| Braking System | |
| Brakes | Tektro Aries mechanical disc brakes w/ 160 front rotor, 160mm rear rotor |
| Brake Levers | Shimano EF-41 |
| Other Components | |
| Grips | Dual density Sport |
| Handle Bar | Pivit riser bar, 25mm rise, 680mm width, 31.8mm clamp |
| Stem | Pivit forged alloy, 10 degree rise |
| Seat | Haro Dual Sport |
| Seat Post | Pivit alloy micro adjust, 30.9 x 350mm |
| Seat Clamp | Pivit alloy 34.9 quick release |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 14 ST | 72° | 73° | 595mm (23.4") | 355mm (14") | 460mm (18.1") | 60mm (2.4") | 1092mm (43") | 709mm (27.9") | |||||||
| 17 ST | 72° | 73° | 602mm (23.7") | 430mm (16.9") | 460mm (18.1") | 60mm (2.4") | 1098mm (43.2") | 727mm (28.6") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
