FEATURES
- 6061 series alloy frame with PTC (Power Transfer Center), integrated head tube, triple butted air formed top tube – 20.75", over sized triple butted down tube, BB86 bottom bracket shell, tapered stays and 3D dropouts with integrated chain tensioners
- 100% chromoly fork with tapered legs
- 100% chromoly 8" bars and Haro CNC alloy front load stem
- 2-piece alloy 175mm cranks with sealed press fit BB86
- Fully sealed wheels with Alienation PBR rims, a sealed 16t rear cassette hub and alloy nipples
- Kenda Konversion 20 x 1.95" front and 1.65" rear tires
- Plastic Pivotal seat with alloy post
- Promax V-Brake and lever
| Frame Components | |
|---|---|
| Frame | 6061 alloy with integrated head tube and PTC - 20.75" TT. |
| Fork | Full Crmo 1-1/8" Threadless with tapered legs |
| Drivetrain | |
| Cranks | 2-pc alloy 175mm / Sealed bearing press-fit BB86 |
| Gearing | 44/16 |
| Pedals | Haro DX Alloy |
| Wheels | |
| Tires | Kenda "Konversion" K1079 20x1.95 F/20x1.65 R |
| Wheels/Rims | Alienation PBR Alloy 36H |
| Hubs | 36h Alloy Shell sealed bearing; 36h Alloy Shell sealed bearing cassette |
| Braking System | |
| Rotor | N/A |
| Other Components | |
| Grips | Velo Knurled Grips |
| Handle Bar | Crmo 8" rise / Haro Alloy CNC front load 52mm ext |
| Seat | Plastic Pivotal seat w/alloy Pivotal post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 20.75 | 74° | 72° | 527mm (20.75") | 240mm (9.4") | 364mm (14.3") | 292mm (11.5") | 562mm (22.1") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
