FEATURES
- 100% crmo frame with butted top and down tubes, tapered stays, Mid BB shell, integrated head tube, integrated seat clamp and removable brake and cable mounts - 20.5" or 21" top tube
- 100% crmo fork with internal threaded CNC 1 piece steer tube and tapered legs
- 100% crmo bars 8.50" (on 20.5") or 8.75" (on 21") with Premium Sub-10 CNC alloy top load stem
- Premium “1948" Three-piece crmo 175mm 48-spline cranks with sealed Mid BB
- 28/9 gearing with alloy sprocket
- Fully sealed wheels with Samsara front and rear double-wall rims and female axle front and rear hubs
- Premium CK tires 2.4" front and rear
- Premium Fat Capitol seat with alloy Pivotal post
- Premium loose ball plastic pedals
- KMC half link chain
| Frame Components | |
|---|---|
| Frame | Full Crmo, butted TT/DT, tapered stays, Mid BB |
| Fork | Full Crmo w/ 1pc CNC steerer and tapered legs |
| Drivetrain | |
| Cranks | Premium 1948 175mm 48 spline w/Sealed MID BB |
| Gearing | 28/9 |
| Pedals | Premium plastic loose ball |
| Wheels | |
| Tires | Premium CK 20x2.40 F/R |
| Wheels/Rims | Premium Samsara 36H Alloy double wall F/R |
| Hubs | 36H Alloy shell sealed bearing female 3/8"; 36H Alloy sealed bearing cassette 9T female 14mm |
| Braking System | |
| Rotor | N/A |
| Other Components | |
| Grips | Premium Counterfeit |
| Handle Bar | Crmo 8.50"/8.75" w/CNC alloy Sub-10 top load stem |
| Seat | Premium Fat Capitol Pivotal w/alloy Pivotal post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 20.5 | 75° | 71.5° | 520mm (20.5") | 247mm (9.7") | 349mm (13.7") | 292mm (11.5") | 533mm (21") |
| 21 | 75° | 71.5° | 533mm (21") | 247mm (9.7") | 349mm (13.7") | 292mm (11.5") | 533mm (21") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
