FEATURES
- CK 100% crmo frame with butted top and down tubes, heat treated tapered stays and dropouts, hour glass Mid BB shell, integrated head tube, integrated seat clamp and removable brake and cable mounts - 20.8" top tube
- CK 100% heat treated crmo fork with internal threaded one piece CNC steer tube, tapered legs, investment cast dropouts and CNC alloy pre-load cap
- CK 100% heat treated crmo bars 8.25"
- Premium 2 piece crmo 175mm 48 spline cranks with 22mm spindle and 28t crmo spline drive sprocket
- Premium Samsara wheels, fully sealed with female axles front and rear, double-wall rims and LSD free-coaster rear hub with 9t driver
- Premium CK tires 2.4" front and rear
- Premium slim plastic pedals with sealed bearings
- Premium Sub-10 V3 CNC front load stem
- Premium Fat Capitol Pivotal seat with alloy Pivotal post
- Premium Chadow pegs (1 pair)
- KMC half link chain
| Frame Components | |
|---|---|
| Frame | Full Crmo CK, butted DT, heat treated tapered stays |
| Fork | Full Crmo CK, heat treated, CNC steerer w/ tapered legs |
| Drivetrain | |
| Cranks | Premium 2pc 48 spline 175mm w/Sealed 22mm MID BB |
| Gearing | 28/9 |
| Pedals | Premium Slim plastic w/sealed bearings |
| Wheels | |
| Tires | Premium CK 20x2.40 F/R |
| Wheels/Rims | Premium Samsara 36H Alloy double wall F/R |
| Hubs | 36H Alloy sealed bearing female 3/8"; 36H Alloy LSD free-coaster w/ male axle & 9T driver |
| Braking System | |
| Rotor | N/A |
| Other Components | |
| Grips | Premium Counterfeit |
| Handle Bar | Full Crmo CK 8.25" w/CNC Alloy Sub-10 V3 stem |
| Seat | Premium Fat Capitol Pivotal w/ alloy Pivotal post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 20.8 | 75° | 71.5° | 528mm (20.8") | 247mm (9.7") | 349mm (13.7") | 292mm (11.5") | 533mm (21") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
