If your adventures include rough road surfaces or bumpy dirt paths, the 26-inch wheels of the 2014 Lxi 6.1 feature 2.125-inch tread width for superior traction and off-road comfort. An upright seating position with comfortable saddle, suspension seatpost and front suspension fork with lockout further enhance the off-road comfort of the Lxi 6.1. To help make molehills out of mountains, a smooth-shifting and quiet 7 speed Shimano drivetrain further enhances the go-anywhere attitude
of the Lxi 6.1.
FEATURES
- Del Sol Lightweight 6061 aluminum exclusive upright comfort frame
- Custom Del Sol comfort plush saddle with suspension seat post
- Ultra-compliant 50mm travel suspension fork
- Shimano Altus rear derailleur powered by Shimano
- Shimano 7 speed Revo Twist shifters
- Alloy adjustable rise comfort stem
- Smooth rolling 26-inch all-purpose tires on double-wall alloy rims
| Frame Components | |
|---|---|
| Frame | Lxi 6061 alloy frame |
| Fork | HL C-420E, 50mm travel |
| Drivetrain | |
| Cranks | SR Suntour XR-172 42/32/22 w/ sealed cartridge |
| Front Derailleur | Shimano Tourney TZ-30 |
| Rear Deralleur | Shimano Tourney TX-35 |
| Derailleur Shifter | Shimano Revo Twist Shifter, 3x7 speed |
| Pedals | Comfort w/Kraton rubber inserts |
| Wheels | |
| Tires | CY Comfort 26 x 1.95" |
| Wheels/Rims | Doublewall DH-18 |
| Hubs | Alloy 32h cassette w/ quick release |
| Freewheel/Cassette | Shimano HG 20- 12-32T 7 speed |
| Braking System | |
| Brakes | Promax TX-117 linear pull |
| Brake Levers | Tektro alloy with Kraton insert |
| Other Components | |
| Grips | Velo Comfort |
| Handle Bar | Steel riser bar, 80mm Rise |
| Stem | Adjustable stem |
| Seat | Del Sol Comfort |
| Seat Post | Suspension 27.2 x 300mm |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 14 ST | 70.5° | 72.5° | 561mm (22.1") | 355mm (14") | 437mm (17.2") | 1021mm (40.2") | 648mm (25.5") | ||||||||
| 17 ST | 70.5° | 72.5° | 580mm (22.8") | 430mm (16.9") | 437mm (17.2") | 1045mm (41.1") | 659mm (25.9") | ||||||||
| 14 | 70.5° | 72.5° | 522mm (20.6") | 355mm (14") | 437mm (17.2") | 1021mm (40.2") | 680mm (26.8") | ||||||||
| 17 | 70.5° | 72.5° | 531mm (20.9") | 430mm (16.9") | 437mm (17.2") | 1045mm (41.1") | 736mm (29") | ||||||||
| 20 | 70.5° | 72.5° | 558mm (22") | 508mm (20") | 437mm (17.2") | 1070mm (42.1") | 763mm (30") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
