The Annex line offers a wide variety of sizes and the next size up from the Mini is the Annex Junior. The Junior comes equipped with a 18.3" top tube 6061 alloy frame and 155mm 3 piece alloy cranks appropriately sized for great handling and final drive ratio. Steering you in the right direction are a 100% chromoly fork coupled with alloy bars and a front load alloy stem. Rounding out the package are 28 spoke alloy wheels which are both fast and durable.
FEATURES
- 6061 series alloy frame with 3D dropouts with integrated chain tensioners
- 100% chromoly fork
- Alloy bars and Haro alloy front load stem
- Haro 3-piece alloy race cranks with sealed Euro BB
- 28-spoke wheels with 20" DA16 double wall alloy rims
- Velo Unibody seat with built in alloy post
- Kenda Kompact tires
- Promax V-Brake and lever
| Frame Components | |
|---|---|
| Frame | 6061 Series Alloy Frame w/ 3D Dropouts w/ Built In Chain Tensioners |
| Fork | Full Cr-Mo 1" Threadless |
| Headset | Threadless Loose Ball, 1" |
| Drivetrain | |
| Cranks | 3-pc Alloy Race, 155mm |
| Sprocket | 36t Alloy |
| Bottom Bracket | Sealed Bearing Euro Square Taper |
| Gearing | 36/13 |
| Chain | KMC 410 |
| Pedals | Mini DX Alloy, 9/16" |
| Wheels | |
| Tires | Kenda "Kompact" 20 x 1 1/8" |
| Wheels/Rims | 20" Alloy 28h, Double Wall |
| Front Hub | Alloy 28h, Loose Ball |
| Rear Hub | Alloy Flip-Flop 28h, Loose Ball |
| Axle | 3/8" |
| Freewheel/Cassette | 13T Freewheel |
| Braking System | |
| Brakes | Promax MV-87 Alloy V-Brake |
| Brake Levers | Promax XL-378 Alloy Lever |
| Other Components | |
| Grips | Mini Micro-Knurl Grips |
| Handle Bar | Alloy Bar, 5" Rise |
| Stem | Forged Alloy Top-Load, 45mm Ext. |
| Seat | Unibody |
| Seat Post | Alloy, 22.2mm |
| Seat Clamp | Alloy, 25.4mm |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 20 | 73° | 71° | 464.9mm (18.3") | 232.7mm (9.2") | 346mm (13.6") | 280mm (11") | 495.3mm (19.5") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
