FEATURES
- 6061 series alloy frame with triple butted air formed top tube - 20.75", triple butted down tube, tapered stays and integrated head tube
- 100% chromoly fork with tapered legs
- 100% chromoly 8" bars and Haro alloy front load stem
- 2-piece alloy 175mm cranks with sealed external Euro BB
- Fully sealed wheels with Alienation PBR rims, a sealed 16t rear cassette hub and alloy nipples
- Kenda Konversion 20 x 1.95" front and 1.65" rear tires
- Plastic Pivotal seat with alloy post
- Alloy V-Brake
| Frame Components | |
|---|---|
| Frame | 6061 Alloy w/ "SPF" formed TT - 20.75" TT |
| Fork | Full Crmo 1-1/8" threadless w/ tapered legs |
| Drivetrain | |
| Cranks | 2-pc alloy 175mm, external Euro sealed bearing BB |
| Gearing | 44/16 cassette cog |
| Pedals | Platform DX style alloy |
| Wheels | |
| Tires | Kenda "Konversion" K1079 20x1.95 F/20x1.65 R |
| Wheels/Rims | Alienation PBR 36H alloy front and rear |
| Hubs | 36H Alloy shell sealed bearing / Cassette rear |
| Braking System | |
| Rotor | N/A |
| Other Components | |
| Grips | Velo micro knurled grips |
| Handle Bar | Full Crmo 8" rise |
| Seat | Haro plastic Pivotal seat w/Pivotal post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 20.75 | 74° | 72° | 527mm (20.75") | 240mm (9.4") | 364mm (14.3") | 292mm (11.5") | 562mm (22.1") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
