FEATURES
- 6061 series alloy frame with butted down tube, tapered chain stays, integrated head tube and 18.9" top tube
- 100% chromoly 1" threadless fork
- Expert 6.75" rise alloy bars and Haro alloy front load stem
- 3-piece 170mm alloy race cranks with sealed Euro BB
- 28-spoke sealed wheels with 20" Alienation Ankle Biter rims, 15t cassette rear hub and alloy nipples
- Kenda Kompact 20x1-3/8" tires
- Velo Unibody seat with built-in alloy post
- Alloy V-Brake
| Frame Components | |
|---|---|
| Frame | 6061 Alloy w/ integrated HT and 3D dropout - 18.90" TT |
| Fork | Full Crmo 1" threadless |
| Drivetrain | |
| Cranks | 3-pc alloy 170mm, Euro sealed bearing BB |
| Gearing | 38/15 cassette cog |
| Pedals | Mini platform DX style Alloy |
| Wheels | |
| Tires | Kenda "Kompact" K1054 20x1 3/8" |
| Wheels/Rims | Alienation Ankle Biter Alloy 28H |
| Hubs | 28H Alloy shell sealed bearing / Cassette rear |
| Braking System | |
| Rotor | N/A |
| Other Components | |
| Grips | Velo micro knurled grips |
| Handle Bar | Expert Alloy 6.75" rise |
| Seat | Plastic unibody one piece w/Alloy post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 18.87 | 73° | 71° | 479.5mm (18.87") | 233mm (9.2") | 349mm (13.7") | 280mm (11") | 495.3mm (19.5") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
