FEATURES
- Full hi-ten frame with internal head tube, Mid BB shell and 20.5" top tube
- Full hi-ten fork with tapered legs
- Hi-ten 8.50" bars with Haro alloy front load stem
- 3-piece chromoly 8-spline 175mm cranks with sealed Mid BB
- 25/9 gearing with sealed bearing rear hub and driver
- Haro La Mesa tires 2.4" front and rear
- Haro padded one piece seat with built-in alloy post
- Haro Team grips
| Frame Components | |
|---|---|
| Frame | Hi-ten frame with internal HT and Mid BB shell - 20.5" TT |
| Fork | Hi-Ten 1 1/8" Threadless with tapered legs |
| Drivetrain | |
| Cranks | 3 pc Crmo 8 spline 175mm w/ Mid sealed bearing BB |
| Gearing | 25/9 |
| Pedals | Haro "Recycled" plastic |
| Wheels | |
| Tires | Haro La Mesa 20x2.40 F/R |
| Wheels/Rims | 36H Alloy single wall |
| Hubs | 36H Alloy Shell loose ball w/ 3/8" axle; 36H Alloy Shell sealed bearing w/14mm axle & 9T driver |
| Braking System | |
| Rotor | N/A - straight cable |
| Other Components | |
| Grips | Haro Team grip |
| Handle Bar | Hi-ten 8.5" rise / Haro Alloy front load stem |
| Seat | Padded one piece seat w/ built in post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 20.5 | 74.5° | 70° | 520mm (20.5") | 250mm (9.8") | 349mm (13.7") | 292mm (11.5") | 546mm (21.5") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
