Blackout

Year 2023
MSRP $1,249.99 *
Sizes 21", 21.5"
Colors Black
Weight

Lights on for the Blackout. Full-sized and race ready. Built on a heat-treated 6000 series aluminum frame with PTS Disc brake mounting and internal cable routing for a clean look and rattle-free rolling at the highest speeds. Add on a state-of-the-art Citizen Carbon fork with 20mm through axles front and rear. All sealed bearings. 2-piece forged alloy 175mm cranks with a 30mm hollow spindle. Kenda Konversion tires speed you up, a Promax disc brake slows you down. Two frames sizes: XL 21" and XXL 21.5". Sold without pedals, because we know everyone has their own preferences...

FEATURES

  • 6061-T6 Heat Treated Alloy PTC Disc Frame w/ Integrated Tapered Headtube, Internal Cable Routing, Smooth Welding & Haro 3D Dropouts w/ Integrated Chain Tensioner
  • Citizen Carbon Fork w/ Tapered Alloy Steerer & 20mm Thru-Axle Dropouts
  • 2-pc Hollow Forged Alloy w/ 30mm Hollow Spindle - 175mm - 44t Alloy Chainring
  • Low Flange Alloy 36h, Sealed Bearing, 20mm Thru-Axle Front w/ Low Flange Alloy Disc Rear
  • Promax DSK-300 Mechanical Disc Brake, 160mm Rotor
  • Kenda "Konversion" 20 x 1.95" Front / 20 x 1.75" Rear
SPECIFICATIONS
Frame Components
Frame 6061-T6 Heat Treated Alloy PTC Disc Frame w/ Integrated Tapered Headtube, Internal Cable Routing, Smooth Welding & Haro 3D Dropouts w/ Integrated Chain Tensioner
Fork Citizen Carbon Fork w/ Tapered Alloy Steerer & 20mm Thru-Axle Dropouts
Headset 1 1/8" X 1.5" Sealed Bearing
Drivetrain
Cranks 2-pc Hollow Forged Alloy w/ 30mm Hollow Spindle - 175mm - 44t Alloy Chainring
Bottom Bracket Cliq Press-Fit BB86 Sealed Bearing
Gearing 44/16
Chain KMC Z33
Pedals N/A
Wheels
Tires Kenda "Konversion" 20 x 1.95" Front / 20 x 1.75" Rear
Wheels/Rims 20" Alloy 36h, Double Wall
Front Hub Low Flange Alloy 36h, Sealed Bearing, 20mm Thru-Axle
Rear Hub Low Flange Alloy Disc
Freewheel/Cassette 16t Cassette
Spokes 14g
Braking System
Brakes Promax DSK-300 Mechanical Disc Brake, 160mm Rotor
Brake Levers Promax V-Point CNC Two Finger
Other Components
Grips Promax Click Grip
Handle Bar Cliq Addict 8" Rise, Heat Treated Cr-Mo
Stem CNC Haro Top-Load, 52mm Ext.
Seat Box Echelon Plastic Seat Combo
Seat Post Carbon, 27.2mm
Seat Clamp QR Alloy, 31.8mm
GEOMETRY
Size Head Angle Seat Angle Top Tube Seat Tube Chainstay BB Height Stand Over
21 74° 72° 533mm (21") 235.5mm (9.27") 389.5mm (15.35") 293mm (11.5")
21.5 74° 72° 546mm (21.5") 235.5mm (9.27") 389.5mm (15.35") 293mm (11.5")

RESOURCES

Owner's manual: Bike Manual PDF

*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
