FEATURES
- Cr-Mo down tube frame with Mid BB shell, integrated head tube and integrated seat clamp
- Internal threaded Cr-Mo steer tube fork with hi-ten tapered legs
- Hi-ten bars 8.50" (on 20" and 20.5") or 8.75" (on 21") with Premium alloy front load stem
- Three-piece Cr-Mo 175mm 8-spline cranks with sealed Mid BB
- 25/9 gearing
- Alienation PBR rims
- Premium CK tires 2.4" front and 2.2" rear
- Premium padded seat with built-in alloy post
- Odyssey Twisted plastic pedals
| Frame Components | |
|---|---|
| Frame | Crmo down tube w/ Mid BB and Integrated HT - 20", 20.5" or 21" TT |
| Fork | Crmo internal threaded steerer w/Hi-ten tapered legs |
| Drivetrain | |
| Cranks | 3 pc. tubular Crmo 175mm w/sealed MID BB |
| Gearing | 25/9 w/loose ball one piece 9T driver |
| Pedals | Odyssey plastic pedals |
| Wheels | |
| Tires | Premium CK 20x2.40 F / 20x2.2 R |
| Wheels/Rims | 36h Alienation PBR alloy SW front and rear |
| Hubs | 36h alloy shell 3/8" Frt / Alloy shell loose ball 14mm rear w/9T driver |
| Braking System | |
| Rotor | N/A Straight Cable |
| Other Components | |
| Grips | Premium Counterfeit |
| Handle Bar | Hi-ten - 8.50" rise w/20" & 20.5" frame, 8.75" rise w/21" frame |
| Seat | Premium padded one piece seat with built in post |
| Pegs | N/A |
| Size | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
|---|---|---|---|---|---|---|---|
| 20 | 75° | 72° | 508mm (20") | 260mm (10.2") | 349mm (13.7") | 293mm (11.5") | 560mm (22") |
| 20.5 | 75° | 72° | 520mm (20.5") | 260mm (10.2") | 349mm (13.7") | 293mm (11.5") | 560mm (22") |
| 21 | 75° | 72° | 533mm (21") | 260mm (10.2") | 349mm (13.7") | 293mm (11.5") | 560mm (22") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
